2025 KAWASAKI TERYX4 BASE - NEON
UTV | Kawasaki
Sale
Save $3,500incl. $2,000 Kawasaki rebate
Stock #BB-R35102
ModelTeryx4 Base - Neon
Features
Highlights
- Powerful 783cc V-twin engine
- Speed-Sensitive Electric Power Steering (EPS)
ADDITIONAL VEHICLE FEATURES
- Maxxis Bighorn tires
- Double-X steel tube frame
- Additional DC outlet in rear
FEATURING
- 783 cc V-twin engine
- Speed-sensitive Electric Power Steering (EPS)
- FOX LSC Piggyback Shocks
- Roomy seating for 4
- Kawasaki Strong 3-Year Limited Warranty
DURABILITY
- Built Strong — Teryx4 side by sides are built around a double-X steel tube frame, welded strong to ensure maximum rigidity.
- Durable & Reliable — Sealed rear wet brake delivers strong braking performance and requires almost no maintenance.
- Dependable Protection — An all-steel front brush guard helps protect bodywork.
POWER
- V-twin Power — V-twin fuel-injected 783cc engine produces the power necessary to take on challenging terrain.
- Capable & Precise — Power delivery is instant thanks to the automatic Continuously Variable Transmission (CVT) and centrifugal clutch.
PERFORMANCE
- Capable & Agile — A tight 5.1 m* turning radius and Electric Power Steering (EPS) allow you to easily take on narrow trails.
- Premium Components — For demanding terrain that requires high-performance suspension components, Teryx4 side by sides are equipped with independent A-arms and premium FOX LSC Piggyback Shocks (coil-over, front and rear).
- Confidence Inspiring — Teryx4 side by sides come equipped with dual front disc brakes that pack the stopping power needed to confidently take on the toughest trails.
- Wide-tread, long wheelbase chassis
COMFORT & CONVENIENCE
- Comfortable & Roomy — Teryx4 side by sides feature stadium-style seating with plenty of head, shoulder and leg room.
- Useful & Convenient — Dash-mounted multifunction digital display meter provides convenient vehicle information at a glance, including total distance traveled, water temperature, and low-oil pressure indicators.
- Smooth & Easy — Speed-sensitive Electric Power Steering (EPS) enhances performance by offering added assistance at lower speeds and great feedback at higher speeds.
Specifications
| Frame | Double-X reinforcement type, tubular carbon steel |
| Engine | 783cc, liquid-cooled, 4-stroke, SOHC 4-valve-per-cylinder 90° V-twin |
| Ignition | Battery & coil (transistorised ignition) |
| Lighting | 2x halogen headlights |
| Starting | Electric |
| Steering | Rack and pinion with Electric Power Steering |
| Warranty | 36 months |
| Wheelbase | 2,175 mm (85.6 in) |
| Rear Brake | Enclosed wet multi-plate |
| Rear Tires | MAXXIS 26 x 11R12 6PR |
| Final Drive | 2WD/4WD, shaft |
| Front Tires | MAXXIS 26 x 9R12 6PR |
| Fuel System | Fuel injection: ø36 mm x 2 |
| Lubrication | Forced lubrication, wet sump |
| Seat Height | 855 (F) / 910 (R) mm (33.7 (F) / 35.8 (R) in) |
| Tread (F/R) | 1,295 mm (51.0 in) / 1,275 mm (50.2 in) |
| Curb Weight* | 728 kg (1,605 lb) |
| Front Brakes | Dual ø200 mm discs with two-piston calipers |
| Rake / Trail | 4.2° / 22 mm |
| Transmission | Dual range CVT with centrifugal clutch and reverse |
| Bore X Stroke | 85.0 x 69.0 mm |
| Fuel Capacity | 30 litres |
| Parking Brake | Enclosed wet multi-plate |
| Road Clearance | 285 mm (11.2 in) |
| Turning Radius | 5.1 m (16.7 ft) |
| Instrumentation | Multi-function digital meter with digital speedometer, bar-style fuel gauge, clock, odometer, dual trip meters, hour meter, 2WD/4WD indicator, front differential lock indicator light, neutral indicator lamp, reverse indicator lamp, parking indicator lamp, water temperature warning indicator, fuel injection warning indicator, oil pressure warning lamp |
| Towing Capacity | 590 kg (1,300 lb) |
| Seating Capacity | 4 |
| Compression Ratio | 10.7:1 |
| Cargo Bed Capacity | 113 kg (250 lb) |
| Dimensions (Lx Wx H) | 3,185 x 1,525 x 1,975 mm (125.4 x 60.0 x 77.8 in) |
| Steering Angle (L/R) | 40° (IN) / 32° (OUT), 40° (IN) / 32° (OUT) |
| Vehicle Load Capacity | 503 kg (1,109 lb) |
| Kawasaki Protection Plus | 12 / 24 / 36 / 48 months |
| Cargo Bed Dimensions (Lx Wx H) | 455 x 1,210 x 220 (F) / 125 (R) mm (17.9 x 47.6 x 8.7 (F) / 4.9 (R) in) |
| Rear Suspension / Wheel Travel | Double wishbone, FOX 2.0 LSC Piggyback Shocks, fully adjustable preload, and adjustable compression damping / 210 mm (8.3 in) |
| Front Suspension / Wheel Travel | Double wishbone, FOX 1.5 LSC Piggyback Shocks, fully adjustable preload, and adjustable compression damping / 202 mm (8.0 in) |
