2026 KAWASAKI KLX140R L - BRIGHT WHITE
Dirt Bike | Kawasaki
Stock #BB-M90458
ColorBright White
ModelKLX140R L
Features
Highlights
- Larger wheels and taller seat height
- Front and rear disc brakes
ADDITIONAL VEHICLE FEATURES
- Larger wheels (F19”, R16”) contribute to a taller seat height (800 mm [31.5 in]) and higher 255 mm (10.0 in) ground clearance
- 180 mm (7.1 in) of front and rear suspension travel
- Disc brakes front and rear
- 95 kg curb weight* (89 kg estimated dry weight**)
FEATURING
- Push-button electric start
- High-revving 144 cc air-cooled, SOHC, four-stroke single
- 5-speed transmission with manual clutch
Specifications
| Frame | Perimeter, box-section, high-tensile steel |
| Power | 8.3 kW {11 PS} / 8,000 rpm |
| Clutch | Wet multi-disc, manual |
| Engine | 144cc, air-cooled, 4-stroke, SOHC 2-valve single |
| Torque | 12 Nm {1.2 kgfm} / 6,000 rpm |
| Ignition | Digital DC-CDI |
| Starting | Electric |
| Warranty | 6 months |
| Rear Tire | 90/100-16 52M |
| Wheelbase | 1,285 mm (50.6 in) |
| Front Tire | 70/100-19 42M |
| Rear Brake | ø186 mm petal disc with single-piston caliper |
| Final Drive | Chain |
| Front Brake | ø220 mm petal disc with dual-piston caliper |
| Fuel System | Carburettor: Keihin PB20 |
| Lubrication | Forced lubrication, wet sump |
| Seat Height | 800 mm (31.5 in) |
| Curb Weight* | 95 kg (209 lb) |
| Rake / Trail | 27.0° / 96 mm |
| Transmission | 5-speed, return |
| Bore X Stroke | 58.0 x 54.4 mm |
| Fuel Capacity | 5.8 litres |
| Road Clearance | 255 mm (10.0 in) |
| Compression Ratio | 9.5:1 |
| Steering Angle (L/R) | 41° / 41° |
| Dimensions (L X W X H) | 1,895 x 790 x 1,075 mm (74.6 x 31.1 x 42.3 in) |
| Estimated Dry Weight** | 89 kg (196 lb) |
| Kawasaki Protection Plus | 12 / 24 / 36 / 48 months |
| Rear Suspension / Wheel Travel | Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable spring preload / 180 mm (7.1 in) |
| Front Suspension / Wheel Travel | ø33 mm telescopic fork / 180 mm (7.1 in) |
